Water connection from the back or top via mounting holes | G1/2 " |
Functional range of water pressure | 0,05 – 1,6 MPa |
Recommended range of water pressure | 0,3 – 0,5 MPa |
The default setting of large flush | 6 l |
The default setting of small flush | 3 l |
Hygienic reserve | 3 l |
Water volume in the cistern | 9 l |
Application
For walling in and around – installation depth only 84 mm
For installing the stand-alone WC or a WC that is firmly embedded in the floor
Technical
Big Flush 6-9L
Small Flush 2.5 - 3.5L
Default Big Flush Setting 6L
Default Small Flush Setting 3L
Water Volume in Cistern 9L
Load test - 400KG
Specifications
Angle valve with the ability to connect to the Mepla piping system
The construction of polystyrene insulation prevents condensation forming on the surface of the tank and dampens the vibrations from the tank into the building structure
Dual flush independently adjustable with hygienic reserve
Compatible with all ALCA flush plates
The cistern is made of one piece, thus ensuring 100% impermeability
Water supply from the rear/top
Maintenance work without using any tools
The service opening cover simplifies assembly and prevents the penetration of moisture and impurities
Mounting height 1070 mm
Installation depth adjustable from 20–60 mm
Installation depth 84 mm
Material: polypropylene
EAN: 8595580550981
